Mazda Protege Engine Components

Water pump gasket for FS-DE water pump

K&N Performance Gold® Oil Filters Originally developed for demanding auto race applications, our premium oil filter is rapidly becoming a favorite among consumers for its durability and easy removal. We’ve changed oil filters and several of our product development technicians are sportsman class drag racers. They insisted we offer an oil filter that corrected the “headaches” they experienced over the years changing oil filters.

King Bearings rod bearing set for Mazda Protege FS Engines.

These valve seals are required when using the Supertech Dual Valve Springs and the Supertech valve guides.

Quality MLS head gasket.

Rod bearings for the FS engine.

Urethane engine mounts reduce drive line lash caused by stock rubber mounts which are too soft. Gives tighter more precise shifting and better throttle response. Precious horsepower is lost with the flex and give of the stock rubber mounts. These stiffer mounts greatly reduce engine flex and transfer more of that valuable force and horsepower to the street.

Urethane engine mounts reduce drive line lash caused by stock rubber mounts which are too soft. Gives tighter more precise shifting and better throttle response. Torque is lost with the flex and give of the stock rubber mounts. These stiffer mounts greatly reduce engine flex and transfer more of that valuable force and horsepower to the ground.

Available in hard, medium and soft compounds.

Replacement torque-to-yield head bolts with washers. Set of 10.

Multi Layered Steel (MLS) head gaskets from Cometic have enjoyed the best reputation among head gasket manufacturers around the world. They are proven to withstand high cylinder pressures without fail. Reccomended for high power, high heat, and high boost applications.

84mm MLS .030"

ALSO available in 84.5mm for overbored blocks.

Obtaining the optimum cylinder head-to-block sealing is especially critical in small displacement engines employing high compression pistons or power adders like turbochargers, nitrous oxide and superchargers. That’s why ARP® head studs are popular among leading Sport Compact/Import racers. You should know that ARP® uses a premium grade 8740 alloy that is rated far superior to "aircraft" quality. Then, each stud is precisely heat-treated to 200,000 psi. Following heattreat, each stud is centerless ground to make it as close to perfectly concentric as possible. This procedure involves about ten very slight cuts and results in an exceptionally straight part. It’s important to note that lesser quality studs are not even centerless ground—the material is thread rolled in bar stock form (mostly before heat-treat, when the material is easier to machine). Because ARP® studs are manufactured to such exacting tolerances, you will note that gaskets and cylinder heads literally glide into position and are perfectly aligned—something that won’t happen with inferior quality head studs. ARP® studs are thread rolled after heat-treat, which gives them about 1000% (that’s ten times) better fatigue strength than those studs that are threaded prior to heat-treat. Premium parallel ground washers and Hex nuts (10 each) are also included with each kit. ARP is the leader in fasteners for racing and high performance. More winning teams use ARP fasteners than all others combined. Top quality, exact tolerances, the best materials and machining processes, and the ability to survive the rigors or racing and get you in the winner's circle make ARP fasteners the #1 choice.

Doing a timing job on your Protege? You'll want this timing belt kit which includes the tensioner spring, timing belt, and tensioner.

Multi Layered Steel (MLS) head gaskets from Cometic have enjoyed the best reputation among head gasket manufacturers around the world. They are proven to withstand high cylinder pressures without fail. Reccomended for high power, high heat, and high boost applications.

84.5mm MLS .027"

ALSO available in 84mm for stock bore blocks.

Multi Layered Steel (MLS) head gaskets from Cometic have enjoyed the best reputation among head gasket manufacturers around the world. They are proven to withstand high cylinder pressures without fail. Reccomended for high power, high heat, and high boost applications.

84.5mm MLS .075"

This extra thick head gasket can drop your compression ratio by about half a point, which is great for high boost applications!

ALSO available in 84mm for stock bore blocks.

Multi Layered Steel (MLS) head gaskets from Cometic have enjoyed the best reputation among head gasket manufacturers around the world. They are proven to withstand high cylinder pressures without fail. Reccomended for high power, high heat, and high boost applications.

84mm MLS .075"

This extra thick head gasket can drop your compression ratio by about half a point, which is great for high boost applications!

ALSO available in 84.5mm for overbore blocks.

These ARP main studs are made from 8740 chromemoly steel and have a 190,000 psi tensile-strength rating. They are precision centerless-ground and thread-rolled to Mil-S-8879 specs, with a black oxide finish for corrosion resistance. The kits come complete with hardened washers and high-strength 12 point nuts.

• PEP Oil pan baffles are all Aluminum, bolted assemblies using a high quality trap door and carefully located surfaces to direct oil to the pickup.
• Please take note that the stock baffle must be removed to create space for the PEP baffle system to be installed.
• Designed to fit any Mazda Protege or Mazdaspeed Protege with a 2.0L FS engine

Complete mount on top of transmission for Mazda Protege with 70 or 88, or 95 durometer solid urethane bushings. Improves driveline response by inhibiting driveling lash, putting all that motion to the task of moving the car along.

Completely new fabricated and reinforced mount, silver powder coated. The 70 durometer bushings, which are recommended for the street. The 88 durometer bushings are a bit firmer, and the 95 durometer which are only recommended for racing. These are too hard for the street and may cause undesirable resonance in the car. For street applications, order the mounts with the 70 durometer bushings.

Supertech Valve Springs are made with premium Superclean Chrome Silicon Vanadium Steel Alloy for higher performance and durability at high RPM ranges. The Supertech materials also provide for better memory, which translates into higher performance.

Computer designed to ensure that wire stress levels do not overpass their limits, Supertech Valve Springs are manufactured for long term durability even under the most extreme conditions.

Is your passenger side engine mount torn? Or are you just tired of the stock OEM mount?

This upgraded is the best there is.

Benefits:

• Reduces engine lash
• Reduces wheel hop
• Increases throttle response
• More power put to the ground


+1mm Intake Valves for FS Engines. Set of 8. This item is special order and may require up to 8 weeks for delivery.

+1mm Exhaust Valves for FS Engines. Set of 8. This item is special order and may require up to 8 weeks for delivery.

Includes all thrust washers, main bearings, and rod bearings. Build your engine right and safe with proven OEM Mazda parts designed for your engine.

Designed for the FSDE 2.0 liter engine in your Protege, MP3, Protege5 or Mazdaspeed Protege, you can trust Cometic quality for your high end engine build - whether it be all out forced induction or simple overhaul. This kit includes all gaskets (except the head gasket) for the engine.

In only 17 years Cometic Gasket, Inc. has grown into a leading worldwide supplier of custom and short-run gaskets for the motorsports industry. What originally began in 1989, in a 1200 square foot office with limited production facilities, has transformed to a 40,000 square foot state-of-the-art manufacturing center, located in the heart of the Midwest. Today, Cometic produces and ships more than 5,000 types of gaskets to customers throughout the United States, Europe, Canada, Australia, New Zealand, and Japan.

Since its inception, Cometic Gasket has been committed to producing superior quality gaskets for the hi-performance motorsports market. We believe that customer satisfaction comes from close relationships with customers and attention to detail; these remain as our guiding principles to this day.

To ensure superior performance across a wide variety of engine types and sizes, we manufacture our gaskets from a wide range of materials. Whether the situation calls for the latest in advanced technology like our MLS (Multi-Layer Steel) gasket, or a synthetic blend such as our Aramid Fiber, Cometic has the answer.

We combine these advanced materials with state-of-the-art manufacturing processes to provide custom-tailored solutions to meet the needs of each individual customer. Our design engineers have the ability to analyze the environment the gasket will perform in, select the proper material, and apply the appropriate technology to offer the highest performing gaskets available on the market.

Our involvement in motorsports racing led to the development of breakthrough technologies which are now applied to every gasket we build. Cometic Gasket’s involvement in racing circuits such as AMA, ARCA, Busch, IHRA, IRL, NASCAR and the NHRA, have allowed us to develop gaskets that are proven in the most demanding conditions there are- the racetrack.

Set of 16 lightweight titanium retainers for use with Supertech valve springs.
