Gauges

The new Innovate Motorsports Digital MTX Series Air/Fuel Ratio Gauge utilizes the only 100% digital Wideband air/fuel ratio technology on the market! The award-winning patented DirectDigital™ technology we use is faster and more accurate than common “UEGO” gauges and is now more affordable! In addition, the gauge features a water resistant casing, interchangeable faceplates and bezels, and 2 fully programmable linear analog outputs for use with aftermarket engine managements systems and dataloggers!

KEY FEATURES

• The only 100% digital wideband air/fuel ratio technology!
• Water Resistant 52mm (2 1/16”) round dash-mountable casing is perfect for automotive, powersports, marine, and demanding racing applications
• Built-in Direct Digital™ Wideband Controller reduces wiring and simplifies installation (No LC-1 required)
• Wideband O2 Sensor is compatible with all fuel types (Leaded, Unleaded, Diesel, Methanol, E85, etc)
• Ability to calibrate O2 sensor for increased accuracy
• (2) 0-5v fully programmable linear analog outputs for use with engine management systems “closed-loop” and external dataloggers
• Interchangeable faceplates and bezels: Black and silver bezel, black and white faceplates included
• Large digital readout and programmable “Digital Needle” provides the functionality of a needle style gauge with the pinpoint accuracy of a digital display
• Datalog using LogWorks on your PC
• Serial IN and OUT ports allows for easy

AEM's Digital Boost Display Gauges combine unsurpassed accuracy, speed and control with an easy-to-read digital LED interface that displays boost in 1 PSI increments, and a sweeping LED "needle" that lines the edge and moves as boost from 0 to up to 35 PSI. The boost gauge's digital readout will automatically increase and decrease in intensity due to the built in ambient light sensing photocell.

AEM's digital boost gauges include a 0-5v analog output for use with data loggers and virtually any engine management system, such as the Infinity ECU, Series 2 EMS or AQ-1 Data Logger, making it the perfect solution for users who need to monitor and data log boost at high RPM on tuned engines. Each gauge includes interchangeable silver and black bezels and black and white faceplates to personalize the look of your gauge.

Features:

• Ideal for carbureted or EFI vehicles
• Easy-to-install Plug & Play harness and sensor included
• 24 green LED display lights provide immediate reference to monitored engine function
• Three digit readout in center
• Each gauge comes with interchangeable black/silver bezels and black/white faceplates
• 0-5V analog output included for use with data loggers and virtually any engine management system
• Auto-dimming gauge face and read out lighting
• Brass sensor included
• Standard 52mm (2-1/16”) gauge housing
• 30-4406 displays boost from -30 - 35 PSI

The AEM Digital Fuel Pressure Gauge combines unsurpassed accuracy, speed and control with an easy-to-read digital LED interface that displays fuel pressure in 1 PSI increments, and a sweeping LED "needle" that lines the edge and moves as fuel pressure changes from 0 to 100. The fuel pressure gauge's digital readout will automatically increase and decrease in intensity due to the built in ambient light sensing photocell.

AEM's fuel pressure gauge digital display includes a 0-5v analog output for use with data loggers and virtually any engine management system, such as the Infinity ECU, Series 2 EMS or AQ-1 Data Logger, making it the perfect solution for users who need to monitor and data log fuel pressure at high RPM on tuned engines. Each gauge includes interchangeable silver and black bezels and black and white faceplates to personalize the look of your gauge (0-100 PSI Oil Pressure faceplates are included if you want to monitor and log oil pressure).

Features:

• Displays fuel pressure from 0 to 100 PSI
• Ideal for carbureted or EFI vehicles
• Easy-to-install Plug & Play harness and sensor included
• 24 green LED display lights provide immediate reference to monitored engine function
• Three digit readout in center
• Each gauge comes with interchangeable black/silver bezels and black/white faceplates
• 0-5V analog output included for use with data loggers and virtually any engine management system
• Auto-dimming gauge face and read out lighting
• 100 PSIg brass sensor included
• Standard 52mm (2-1/16”) gauge housing

Dual function gauge that shows oil pressure and temperature

DISPLAY RANGE

• Pressure: 0-150 PSI (7 BAR)
• Temp: 120-280 °F (49-138 °C)


KEY FEATURES

Pressure

• Display in either PSI or BAR (Digital Display)
• Program Low Oil Pressure Warning (Digital Display)

Temperature

• Change exterior LED as a fill bar or light a single indicating LED
• Program exterior LED ranges vs. Color
• Program unit of measure as °F or °C
• Program Oil Temperature Warning (outer LED

These new Innovate MTX digital series gauges are the perfect solution to help maximize limited space on your dash! They feature a water-resistant casing, interchangeable faceplates and bezels, and locking connectors for a simplified installation. They also feature MTS serial connections to connect with other Innovate devices and log onto your PC, iPhone, iPod Touch, iPad, LM-2, or DL-32. (An OT-2 for logging onto your Apple device is not included. LogWorks Mobile v1.13+ is required.) Innovate MTX digital series gauges include one black faceplate, one white faceplate, one black outer bezel, and one silver outer bezel, so you can choose the combination of colors that best fits your ride. They also come with a serial programming cable, a thermistor, a quick-start installation guide (on CD), and a software CD (LogWorks and LM programmer).

Mechanical boost gauge. Vacuum and pressure measured in PSI (30 Max). Nice Garrett logo and color scheme.

• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 30 in Hg.-Vac./30 PSI
• Includes 6 ft. tubing.
• Includes T-fitting.

• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 30 in Hg.-Vac./20 PSI
• Includes 6 ft. tubing.
• Includes T-fitting.

Oil/Transmission/Water temperature digital display gauge. 100-300 F. Four gauge styles in one.

The AEM Digital Oil Temperature Gauge combines unsurpassed accuracy, speed and control with an easy-to-read digital LED interface that displays oil temperature in 1 degree increments, and a sweeping LED "needle" that lines the edge and moves as oil temp changes from 0 to 100. The aftermarket digital oil temp gauge's readout will automatically increase and decrease in intensity due to the built in ambient light sensing photocell.

AEM's digital oil temp gauge includes a 0-5v analog output for use with data loggers and virtually any engine management system, such as the Infinity ECU, Series 2 EMS or AQ-1 Data Logger, making it the perfect solution for users who need to monitor and data log oil temps at high RPM on tuned engines. Each AEM oil temperature gauge includes interchangeable silver and black bezels and black and white faceplates to personalize the look of your gauge.

Features:

• Easy-to-install Plug & Play harness and sensor included
• Gauge Readout from 100 to 300 F
• 24 green LED display lights provide immediate reference to monitored engine function
• Three digit readout in center
• Each gauge comes with interchangeable black/silver bezels and black/white faceplates
• Auto-dimming gauge face and read out lighting
• 0-5v analog output included for use with data loggers and virtually any engine management system
• Brass sensor included
• 52mm (2 1/16th inch) gauge housing

• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 30 In. Hg/30 PSI

• Includes 6 ft. tubing.
• Includes 1/2"" NPT adapter/fitting.
• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 30 In. Hg/30 PSI

• Size: 2 1/16" (52.4mm)
• Type: Full Sweep Electric
• Range:30 In Hg.-Vac./30 PSI

• Full Sweep, Stepper Motor meter movement.
• Includes 8 ft. tubing or wiring harness.
• Includes MAP sensor.
• Includes T-fitting.

• Size: 2 1/16" (52.4mm)
• Type: Short Sweep Electric
• Range: 0 - 100 PSI
• Includes 1/8" NPT Sender.
• Air-Core meter movement.
• Includes 1/4'' NPT adapter/fittings.

• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 0 - 100 PSI
• Includes 6 ft. nylon tubing with 1/8" NPT fittings.
• Includes 1/4'' NPT adapter/fittings.

AEM's Digital Boost Display Gauges combine unsurpassed accuracy, speed and control with an easy-to-read digital LED interface that displays boost in 1 PSI increments, and a sweeping LED "needle" that lines the edge and moves as boost from 0 to up to 50 PSI. The boost gauge's digital readout will automatically increase and decrease in intensity due to the built in ambient light sensing photocell.

AEM's digital boost gauges include a 0-5v analog output for use with data loggers and virtually any engine management system, such as the Infinity ECU, Series 2 EMS or AQ-1 Data Logger, making it the perfect solution for users who need to monitor and data log boost at high RPM on tuned engines. Each gauge includes interchangeable silver and black bezels and black and white faceplates to personalize the look of your gauge.

Features:

• Ideal for carbureted or EFI vehicles
• Easy-to-install Plug & Play harness and sensor included
• 24 green LED display lights provide immediate reference to monitored engine function
• Three digit readout in center
• Each gauge comes with interchangeable black/silver bezels and black/white faceplates
• 0-5V analog output included for use with data loggers and virtually any engine management system
• Auto-dimming gauge face and read out lighting
• Brass sensor included
• Standard 52mm (2-1/16”) gauge housing
• 30-4408 displays boost from -30 - 50 PSI

• 2 1/16" (52.4mm)
• Type: Full Sweep Electric
• Range:0-100 psi

• Full Sweep, Stepper Motor meter movement.
• Includes 1/8" NPT Sender.
• Includes 8 ft. tubing or wiring harness.
• Includes 1/4'' NPT adapter/fittings.

• 2 1/16" (52.4mm)
• Type: Short Sweep Electric
• Range:0-100 psi

• Includes 1/8" NPT Sender.
• Air-Core meter movement.
• Includes 1/4'' NPT adapter/fittings.

• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 30 In. Hg/20 PSI


Notes:

• Includes 6 ft. tubing.
• Includes 1/2"" NPT adapter/fitting.
• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 30 In. Hg/20 PSI

Allows you to monitor your coolant temps.

• Size: 2 1/16" (52.4mm)
• Type: Short Sweep Electric
• Range: 100 - 250 deg. F

Notes:

• Includes 1/8" NPT Sender.
• Air-Core meter movement.
• Includes 3/8"" NPT adapter/fitting.
• Includes 1/2"" NPT adapter/fitting.

• Allows you to monitor your voltage.
• Size: 2 1/16" (52.4mm)
• Type: Full Sweep Electric
• Range: 8 - 18V
• Air-Core meter movement.

This gauge is used in tuning to determine your exhaust gas temps. Engines can only withstand certain gas temperatures before things start to break down. Monitor your temps with this gauge before it's too late!

• Size: 2 1/16" (52.4mm)
• Type: Full Sweep Electric
• Range: 0 - 2000 deg. F
• Air-Core meter movement.
• Includes Type K Thermocouple.

• Size: 2 1/16" (52.4mm)
• Type: Full Sweep Electric
• Range: 0 - 1600 deg. F
• Air-Core meter movement.
• Includes Type K Thermocouple.

• Size: 2 1/16" (52.4mm)
• Type: Mechanical
• Range: 0 - 1600 PSI
• Requires #4 braided hose kit.
